R911311497
The R911311497 (VCP08.2DTN-003-NN-NN-PW) is a product of Bosch Rexroth Indramat, notable manufacturers of industrial control units and terminals. This unit belongs to the VCP range of compact operator terminals, designed to integrate proficiently with serial bus and Fieldbus interfaces.
The operator terminal, a part of versatile applications, can be mounted in any position. It is equipped with a 39-key membrane keyboard for inputting commands. It also features 15 LED status indicators and supports DeviceNet and PROFIBUS DP interfaces. Furthermore, the R911311497 (VCP08.2DTN-003-NN-NN-PW) boasts a RISC ARM9 central processing unit that operates at a clock frequency of 200 MHz. It is equipped with a real-time clock, a watchdog timer, and battery monitoring components. Memory capacity includes 512 KB each of SRAM and SDRAM, a 3 MB application memory, and an additional 16 MB flash memory. The terminal uses D-SUB, Phoenix COMBICON, RJ45 female, and USB female connectors. With a 24 V supply, it operates by consuming 0.25 A current. The connected load stands at 6 W, while the maximum power consumption is at 0.35 A. The panel possesses a significant display area with a 320 x 240 pixel resolution FSTN display screen which exhibits five different gray colors keeping the contrast temperature compensated, with a backlighting half-life of 30,000 hours.
