R911311510
The R911311510 (VCP11.2DWN-003-SR-NN-PW), designed by Bosch Rexroth Indramat, is a compact operator terminal optimised for single or multi-axis control operations. This includes uses in assembly and handling systems, packaging machines, and machine tools. Equipped with an IP 20 approved seal, it resists solid materials and light water exposure. Fabricated from durable materials like galvanized steel and anodized aluminum, it weighs approximately 500g. The device is designed with a 3.8-inch FSTN touchscreen display and can be mounted as desired. It hosts a DC 24V electrical connection via connector X1 and features reverse polarity protection.
Further, the R911311510 (VCP11.2DWN-003-SR-NN-PW) model boasts an ARM9 central processing unit, equipped with battery monitoring, a real-time clock, a watchdog timer, and a 200MHz clock frequency. It has 3 MB of application memory, 16 MB flash, 32 MB SDRAM, 512 Kb SRAM, and two host interfaces. The device uses an RS485 interface for device communication. Additionally, it utilizes an RS232 interface for data exchange and an Ethernet interface for LAN device communication. Capable of operating in a temperature range of +5 to +45 ͦC, it can tolerate up to 85% relative humidity. Vibrations from 10 Hz to 150 Hz are also sustained. Preinstalled firmware is also included.
