R911329659
The R911329659 (HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW) Drive Controller is a highly reliable product from Bosch Rexroth Indramat, esteemed pioneers in automation engineering. Primarily used for speed and position control tasks in automated operations, the drive controller offers movement control across four distinct axes. It is a converter type controller featuring flat design, five encoder evaluations, and includes an interface to the operator panel (LVDS + USB). The device also employs an external braking resistor to manage motor operations. For power, it necessitates a three-phase connection ranging from 200 V to 500 V and showcases a visually intuitive human-machine interface for user-friendly operation. Despite its robust capabilities, the device weighs a manageable 11.7 kilograms.
The R911329659 (HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW)’s compact footprint facilitates installation even in small control cabinets. To combat heat build-up, the controller employs a forced ventilation system. The controller possesses a Sercos III master port, an Ethernet port, 16 digital outputs, and 32 digital inputs. It is also compatible with an additional embedded PC for sophisticated operation. The controller operates with a 44 A rated current and can be installed at heights up to 1000 m above sea level, ideally within an ambiance where temperature does not exceed 40 degrees Celsius to ensure optimal performance.
