R911332026
Original price
$11,742.00
-
Original price
$11,742.00
Original price
$11,742.00
$11,742.00
-
$11,742.00
Current price
$11,742.00
The product under consideration, the R911332026 (HMV01.1E-W0075-A-07-FCN1), is a power supply module originating from Bosch Rexroth Indramat, a renowned name in superior quality control and power supply units. This model particularly functions as a supply unit for Bosch's HMS inverter systems and operates as a rectifier. It is developed with an integrated brake resistor, a component responsible for distributing heat generated from high-speed motors during instant deceleration. This process is facilitated by a fan blower fitted within the device, which ensures optimal motor temperature even with continuous use.
The technical features of the R911332026 (HMV01.1E-W0075-A-07-FCN1) include a short circuit current rating of 42000 A and a three-phase supply module for typical operations. The connection of this module ranges from 380 V to 480 V, and it produces an output of 435 to 710 VDC. It operates with an input current of 128 A and an output of 173 A. The physical dimensions include a height of 440 mm, width of 250 mm, and depth of 262 mm. Weighing in around 22 kg, the device also generates sounds up to 75 db(A). The recommended operating temperature for this module falls between 0 and 40 degrees Celsius.
