R911332800
The R911332800 (CDB01.1C-ET-ENS-ENS-ENS-ENS-S2-S-NN-FW), a basic universal control section designed by Bosch Rexroth Indramat, functions as the core of a drive controller. This controller supervises and manages the motor it's connected to. It contains a relay contact with a pickup and dropout delay of 10ms and probe type digital inputs with a 3mA current rating and 24V voltage rating. Furthermore, the device employs a protective diode in its power supply to guard against supply voltage polarity reversal. The digital inputs and outputs utilize an external supply voltage connection via the X31 connector. Notably, the sixth and seventh digital inputs can be repurposed as analog inputs.
The control section comes equipped with a 9-pin RS 232 serial interface connection located at the X2 connector. The interface, used for sending and receiving data at a minimum transmission rate of 9.6kBaud, connects to the section's power supply with a 15m long cable. For network availability, the H11 and H13 LEDs will light up in green. It must be noted that the device should only come into contact with grounded conductive parts. Intended for use with manufacturer-approved parts, the controller is much sought after in the packaging, printing, food, and paper processing industries.
