R911335595
The R911335595 (HCS01.1E-W0028-A-03-B-ET-EC-NN-L3-NN-FW) is a drive controller by Bosch Rexroth Indramat engineered to regulate the voltage load of a third-party motor with an integrated temperature sensor, functioning in open-loop operation without a motor encoder. The device is designed to operate from inside a control cabinet shielded from conductive dirt, and installation is feasible only in the G1 mounting orientation. It's critical to maintain the prescribed ambient conditions, as the controller's performance might decrease beyond the normal operating temperature or in an elevated location above 4000m sea level.
Weighing in at 1.7kg, the UL Listed and CSA Certified unit cannot be used in proximity to combustible materials or heated over 105°C. An incorporated forced cooling air current, and mandatory clearance above and below the device inside the control cabinet, further assists in temperature management. The R911335595 (HCS01.1E-W0028-A-03-B-ET-EC-NN-L3-NN-FW) controller includes a basic control section with a 17.3W power rating and leaks current due to a three-phase system's imbalance. Its features also include the allowance of a residual current-operated circuit breaker for shielded motor cables longer than 20m. The device requires a safety fuse to protect against overheating from short circuits. Product delivery is available worldwide.
