R911378727
The Bosch Rexroth Indramat product model, R911378727 (KSM02.1B-061C-61N-M1-HG2-ET-SD-D7-NN-FW), is a reliable and efficient distributed servo drive designed to address the challenges of industrial automation. This model boasts excellent operational reliability and flexibility, monitored and controlled by a multiturn-absolute Hiperface Optical Encoder having 128 increments. Operationally, it requires a DC 750V power supply running at a 50/60 Hz frequency and consumes a maximum current of 14.9 A to produce a maximum torque of 18Nm. Capable of reaching up to 6,000 revolutions per minute, the servo drive features class 155 insulation and has a compact design that saves space.
Designed with an IP 65 protective grade, it is safe from dust and liquid infiltration. When stationary, it upholds a continual torque of 5.5Nm given a 60 Kelvin rise in housing temperature. In 20 degrees Celsius surroundings, this servo drive can deliver a torque constant of 1.16 Nm per Ampere. Its output is via a shaft secured via keyway and further protected by a shaft sealing ring. Installation requires a control cabinet with suitable top, bottom and side ventilation gaps. This standard-size model carries a rated control voltage range of 30 to 42V, consuming 33.5W power. The device weighs 10 kg and includes comprehensive mounting instructions.
30 Day Warranty
Technical Specifications
