RBEH-01210-A14

by Kollmorgen
$2,250.00 - $2,250.00
$2,250.00
$2,250.00 - $2,250.00
$2,250.00
In Stock, Ships 1 - 2 Days
The RBEH-01210-A14 is a high-performance brushless servo motor produced by industry-leading manufacturer, Kollmorgen. Suited for an array of industrial uses, this compact yet powerful motor connects directly via external phase connectors (A, B, and C), and functions in conjunction with a Kollmorgen servo amplifier for speed and position control. Capable of 13800 RPM, it provides continuous power of 106W and torque of 0.115 Nm under a continuous current of 5.41 A. Equipped with internal heat sinks to manage temperature, and designed for maintenance-free operation, the RBEH-01210-A14 offers reliability and longevity when adhering to specified environmental and installation conditions. Weighing approximately 0.32kg, this 8-pole motor comes with a winding type "A", and generates 0.698 Ohm of resistance at 25-degree Celsius. It's optimized for easy installation and maximum mechanical speed of 18000 rpm, solidifying its dependability in diverse operational settings.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Product Model: RBEH-01210-A14
  • Product Type: Brushless Servo Motor
  • Electrical Connection: External Phase Connectors (A, B, C)
  • Amplifier Requirement: Kollmorgen Servo Amplifier
  • Power Output: 106 W
  • Speed: 13800 rpm
  • Torque: 0.115 Nm
  • Current: 5.41 A
  • Winding Type: A
  • Winding Inductance: 0.280 mH
  • Winding Resistance at 25 Celsius: 0.698 Ohm
  • Motor Poles: 8
  • Weight: 0.32 kg
  • Maximum Mechanical Speed: 18000 rpm
