The RZR01.1-RD52-0610-P-M-FW is a line-side HPS power stack controller created by Bosch Rexroth Indramat, a leader in industry 4.0 automation solutions. Designed for optimal energy management, this device incorporates a cooling fan and features a field-oriented vector control function (RD52). This controller operates with a maximum efficient current of 610A when linked to a HPS unit, utilizing a parallel circuit method and motor inverter control. It requires an input voltage of 24V and a maximum current consumption of 12A. The unit, weighing 6.5kg, has an IP20-rated enclosure and conforms to DIN IEC 721-3-3's environmental class 3K3. Assembly on an even surface in a vertical position is recommended, keeping an 80mm minimum distance from adjacent components. The cooling fan lifetimes are 80,000 hours at 40°C and 40,000 hours at 70°C. The device should not be deployed in areas with water jets.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Line: 01
  • Design Type: 01
  • Function Controller: RD52
  • Max Current Requirement: 610 Amperes
  • Circuit Technique: Parallel
  • Motor Control Type: Inverter
  • Input Voltage: 24 Volts
  • Max Current Consumption: 12 Amperes
  • Weight: 6.5 kg
  • Enclosure Rating: IP 20
  • Environmental Class: 3K3 (DIN IEC 721-3-3)
  • Noise Suppression Level: A2 (EN 55011)
  • Operating Temperature: 0 – 40 degrees C
  • Position during Assembly: Vertical
  • Allowance to Adjacent Components: 80 mm
  • Fan Lifetime at 40 degrees C: 80,000 hours
  • Fan Lifetime at 70 degrees C: 40,000 hours.
