manufacturer image of SC722A001

SC722A001

by Pacific Scientific
$1,921.71 - $1,921.71
$1,921.71
$1,921.71 - $1,921.71
$1,921.71
Available, Shipping Varies
The SC722A001 is a single-axis servo controller created by Pacific Scientific. Part of the SC720 series, this controller is designed to function as a torque/velocity encoder and is capable of superior performance at 230VAC or 400VDC. It bears a 3.8A constant current and a peak at 7.5A, featuring a 12-bit RDC option code with 1024 pulses per revolution. Designed for brushless servo motors, the controller relies on seven input/output cables for connectivity, including the J1 motor cable for connecting the controller to motor windings. Remember to avoid powering up the unit without its cover or with the chassis grounded. Disconnect the power supply for safe shutdown. Store it in a dry, clean place within temperatures of -25°C to +85°C, and ideally within its original carton. The unit weighs nearly 14 pounds and should be mounted vertically in a 10-inch deep NEMA intended for industrial applications.
30 Day Warranty
Technical Specifications
  • Manufacturer: Pacific Scientific
  • Product Code: SC722A001
  • Product Type: Single Axis Servo Controller
  • Series: SC720
  • Function: Torque/Velocity Controller with Encoder
  • Continuous Current Rating: 3.8A
  • Peak Current Rating: 7.5A
  • RDC Option Code: 12-bit with 1024 ppr
  • Voltage Rating: Exceeding 230VAC and/or 400VDC
  • Cooling Mechanism: Built-in fans
  • Usage Precautions: Do not power up with chassis tied to the earth ground or without cover. Power supply to be disconnected for shut down
  • Intended Motor Type: Brushless Servo Motors from Pacific Scientific
  • Storage Requirements: Clean and dry place, temperature range of -25°C to +85°C, ideally in the original shipping carton
  • Weight: 14 pounds
  • Power Dissipation: 23W at 50% of rated output current
  • Installation: Vertical orientation, using #10 or 1/4-20 bolts in a 10-inch deep NEMA cabinet
  • Cables: 7 input/output cables, including J1 motor cable
  • Connection: Uses mating connectors, tips should not be soldered
  • Resolver Cable: Individually twisted-shielded cable for output pairs.
