S image of SD-B3.031.030-15.001

SD-B3.031.030-15.001

by Bosch Rexroth Indramat
$2,266.90 - $2,266.90
$2,266.90
$2,266.90 - $2,266.90
$2,266.90

In Stock, Ships Fast

The SD-B3.031.030-15.001, produced by Bosch Rexroth Indramat, is a high-performance industrial servo motor designed for precision in production and processing machinery. This new-generation motor combines proven designs with cutting-edge innovations, featuring a sturdy, compact casing rated at IP54 for enhanced protection. Certified to meet industrial safety and operational standards, it employs permanent magnet excitation to support various applications like transfer facilities, textiles, and robotics, providing low inertia and efficient performance. Capable of delivering 0.98 kW of power, the motor operates with a current of 3.25 A, generating 3.1 Nm of torque at speeds up to 3000 RPM. Additionally, it features a high-resolution tacho generator for precise monitoring of speed, position, and torque outputs. It operates within a temperature range of 0 to 40°C and weighs approximately 36 kg, with winding resistance at 6.7 Ohms and inductance at 40 millihenries.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Brand

Bosch Rexroth Indramat

Model

SD-B3.031.030-15.001

Type

Industrial Servo Motor

Protection Class

IP54

Rated Input Current

3.25 Amperes

Rated Torque

3.1 Newton Meters

Maximum Speed

3000 Revolutions per Minute

Rated Power Output

0.98 Kilowatts

Winding Resistance

6.7 Ohms

Winding Inductance

40 Millihenry

Tacho Generator

High Resolution

Ambient Temperature Range

0 to 40 Degree Celsius

Weight

36 Kilograms

Magnet Type

Permanent Magnet

Application

Transfer Facilities, Textile Machines, Robotic Machines
