manufacturer image of SD-B4.092.020-00

SD-B4.092.020-00

by Bosch Rexroth Indramat
Request a quote
The SD-B4.092.020-00 permanent-field servomotor, manufactured by Bosch Rexroth Indramat, operates within the Servodyn system in conjunction with a compatible inverter. It features a nominal speed of 2000 rpm and exhibits a torque of 9.2 Nm at 200 rpm in standstill mode. The motor is cooled through thermal radiation or natural convection and operates efficiently within a temperature range of 0 °C to 40 °C. Equipped with ferrite permanent magnets, the motor meets IP54 protection standards and possesses a design classified as B5. It includes a shaft with a feather key and keyway and is subject to radial and axial forces, as well as multi-directional tension at the shaft-hub connection. Proper handling is crucial as inappropriate inverter pairing or fluid presence with IM V3 mounting can cause damage. Notably, Pin 6 of the power socket must remain unused during operation.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Model: SD-B4.092.020-00
  • Type: Permanent-field servomotor
  • System Compatibility: Servodyn
  • Nominal Speed: 2000 rpm
  • Connection Cross-section: 1.5 mm2
  • Ambient Operating Temperature: 45 °C
  • Sockets: Separate sockets for power and tacho connections
  • Power Socket Pin 6: No connection
  • Braking Mechanism: Shorting windings through braking resistors
  • Shaft: Shaft with featherkey and keyway
  • Disk Brake: None
  • Vibration Quality Level: N according to DIN ISO 2373
  • Permanent Magnet Material: Ferrite
  • Design: B5
  • Protection Standard: IP 54
  • Shaft-Hub Connection: Multi-directional tension under load
  • Operational Suitability: Not recommended for stringent applications
  • Mounting Orientation Prohibition: Cannot use IM V1 orientation
  • Fluid Prohibition Around Shaft: No fluid around the shaft with IM V3 mounting
  • Cooling: Thermal radiation or natural convection
  • Operating Temperature Range: 0 °C to 40 °C
  • Torque at Standstill Mode: 9.2 Nm at 200 rpm
  • Potential Damage: Inappropriate inverter use
  • Radial and Axial Forces: Subject to forces on the shaft during operation
  • Housing Temperature: Hot during operation phase
