The SH1424-5241 from Sanyo Denki is part of the F SANMOTION Stepping Motors series. This 42 mm square motor operates at 24 VDC delivering 2 A per phase in 2-phase full-step energization with a 1.8° step angle. Custom options like hollow shaft are available. A compact 48 mm length and 300 mm cable facilitate industrial automation integration.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Cable Length
300 mm minimum
Custom Options
Hollow Shaft & other designs on request
Energization Mode
2-phase energization (full-step)
Maximum Self-start Frequency (unloaded)
fs: As specified in characteristic diagrams
Motor Size
42 mm square
Operating Current
2 A/phase
Pull-out Torque
JL=0.94×10-4kg·m² (with rubber coupling)
Source Voltage
24 VDC
Step Angle
1.8°/step
