SL3407-00000
by Kollmorgen
The SL3407-00000, a product from Kollmorgen, is a 7.5 HP, panel-mount AC drive operating with a 460 Voltage AC input. As part of the Seco SL3000 series, it is designed with a 12 key keypad and a 2-line 16-character LCD which facilitate easy programming and monitoring. Boasting a microprocessor-controlled circuitry, the drive offers high performance with full digital control, customized application settings, and diagnostic fault monitoring. The braking is executed by either integrated dynamic braking or an optional DC injection. A standard feature includes an RS-485 serial communication interface. The drive is designed to operate adequately under certain ambient conditions including an altitude of up to 1000 meters, a relative humidity between 5 to 95%, and a temperature range of 0 to 55 degrees Celsius. The drive's analog input can control speed with a 1-10V DC range for the local analog input and 0-20 milliamps for the remote analog in order to control speed. Its analog output voltage of 0-10 V DC can be used for measuring speed or torque. It displays a rated AC input and output current of 11 Amps, a peak output power of 8.7 kVA, and a power dissipation capacity of 175 Watts. Ventilation is provided by both internal and external fans.
