S image of SL3410-00000

SL3410-00000

by Kollmorgen
$632.50 - $632.50
$632.50
$632.50 - $632.50
$632.50

In Stock, Ships 1 - 3 Days

The Kollmorgen manufactured Seco SL3410-00000 is an AC drive, made for chassis or panel mounting, and capable of operating AC induction motors. With a 460 Volts AC input voltage rating and 10 Horsepower output, it belongs to the SL3000 series which includes features like micro-processor based control, dynamic braking, alphanumeric display, coast-to-rest / decelerate-to-stop modes, PWM carrier modulation, and serial communication using the ANSI protocol via an RS-485 port. This model comes with an optional internal dynamic braking resistor, operates between 0 and 55 degrees Celsius, and can function up at altitudes up to 3300 feet. Adjustments are supported for maximum speed, acceleration time, deceleration time, maximum current, and slip compensation, with the status display offering detailed monitoring options. It is crucial to adhere to the manual's installation instructions for optimal performance and safety.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Product Type

AC Drive

Model Number

SL3410-00000

Series

SL3000

Input Voltage

460 Volts AC

Output Power

10 Horsepower

Mounting Type

Chassis or Panel

Application

AC Induction Motors

Control Type

Micro-Processor Based Control

Display Type

Alphanumeric

Stop Modes

Coast-to-Rest/Decelerate-to-Stop

Additional Features

Dynamic Braking, PWM Carrier Modulation, Serial Communication

Option Features

Internal Dynamic Braking Resistor

Operating Temperature

0 to 55 degrees Celsius

Operational Altitude

0 to 3300 feet (without derating)

Output Voltage

0 to Input Voltage

Output Frequency

0 to 320 Hertz

Overload Capacity

150% for 1 Minute

Line Protection

Fuses, Capacitors, MOVs

Supported Adjustments

Maximum Speed, Acceleration Time, Deceleration Time, Maximum Current, Slip Compensation

Display Information

Motor Speed, Motor Current, Motor Frequency, Input Signals Status, Hours Run, Last Fault Conditions

Communication Port

RS-485 (Supports ANSI protocol)
