SM13 109-0700-4A06-01
The SM13 109-0700-4A06-01 servo module inverter from Bosch Rexroth Indramat, part of the SM AC Inverters series, delivers versatile performance for demanding industrial and automation environments. With a DC link voltage of 460 V to 700 V and a rated current of 5 A complemented by a peak current of 10 A, this module supports robust power delivery in a compact footprint. It operates on a rated power supply of 24 V DC, 100 mA and draws diagnostics module supply voltage of +24 V ±15%, ensuring compatibility with standard control architectures. Featuring an IP00 ingress protection rating under DIN 40050 and a speed regulation range >1:10,000, the inverter delivers fine-grained control across a wide dynamic range. Designed as a servo module, this unit integrates seamlessly with rotor position encoders and tachogenerators to maintain precise feedback loops. Its operating envelope spans 0°C to +55°C, making it suitable for a broad array of industrial conditions.
Performance is optimized through differential and digital interfaces, including Control inputs for differential command, enable, and torque reduction signals. Feedback is managed by a motor feedback system that accommodates rotor position encoders and tacho voltage inputs for high-resolution position and speed monitoring. The inverter sustains a max acceleration torque current of 70 A for rapid transient response and features a humidity standard Class F (DIN 40040) insulation rating for stable operation in humid environments. Even at elevations up to 1000 m amsl and subject to a max power loss of 60 W, the SM13 maintains consistent regulation performance. Advanced internal circuitry employs general-purpose diodes for rectification and trimpots for precise calibration of voltage and current thresholds, ensuring reliable signal conditioning under varied load profiles.
Engineered for straightforward integration, the module offers a 12-position screw terminal block for analog and digital I/O, plus a 20-pin header connector (X15) for backplane or master controller communication. Reliability is further assured by Schrack RTB14024F relays rated for 250 V AC switching voltage and 10 A switching current, while Westwood Precision ZH-CT04L toroidal current transformers provide non-invasive AC current measurement. Mechanical stability is achieved with plated mounting screws and conformal coated fasteners to withstand industrial vibration and thermal cycling. The inverter’s modular form factor and broad parameter adjustability make it ideal for CNC systems, robotics, packaging machinery, and other automation applications where precise torque control, high-speed regulation, and dependable long-term operation are essential.
