SR06000-000000

The Kollmorgen SR06000-000000 drive from the SP Servostar Servo Drives series is engineered to deliver reliable, high-performance motion control in demanding industrial environments. Manufactured by Kollmorgen, this compact servo drive provides a broad DC input range of 140 VDC / 310 VDC and supports continuous phase currents for precise motor control. With a rated output power of 1 kW / 2.3 kW, it adapts to a variety of motor sizes while maintaining consistent torque delivery. The drive’s lightweight design (2.27 kg) simplifies panel integration and reduces structural support requirements in control cabinets. Critical safety and connection integrity are assured by a 2.25 lb-in. connector screw torque specification for secure electrical contacts.

The SR06000-000000 incorporates a dual-level input power capacity of 1.26 kW / 2.79 kW to match varying supply capabilities and optimize energy efficiency. Its maximum input current is 9 ADC, balanced against a 6 amps/phase rated current output to provide stable drive performance under full load. Output voltage selection of 115 VAC / 230 VAC accommodates global motor standards, and the resolver feedback system ensures precise position sensing with inherent noise immunity. Mechanical robustness is indicated by a vibration resistance of 0.5 G, while the drive’s total mass remains at 2.27 kg, delivering an excellent power-to-weight ratio. The resolver feedback type eliminates the need for supplementary encoders, streamlining the overall system architecture.

Operational resilience is engineered into every aspect of the SR06000-000000. The specified operating temperature range of 0 to +45°C ensures reliable operation across typical factory conditions, while an over-temperature trip set point at 90°C provides automatic thermal shutdown to protect internal components. The drive tolerates ambient humidity between 10 to 90% (non-condensing), guarding against moisture-related performance degradation. The resolver feedback mechanism further enhances performance stability in environments subject to electrical noise and mechanical vibration. Together, these features enable uninterrupted operation in packaging, assembly, and general automation systems.

System integration is streamlined through standard control interfaces and simple panel mounting for efficient cabinet layouts. Compatibility with industry-standard PLCs and motion controllers makes the SR06000-000000 ideal for applications in robotics, CNC machinery, and material handling. Maintenance is facilitated by diagnostic feedback and over-temperature protection, reducing downtime in high-throughput processes. The combination of broad voltage tolerance, secure connections, and advanced feedback positions this drive as a versatile solution for modern industrial automation.
