The Kollmorgen SR3640-293-16-48B is a robust DC motor from the SR and SRF Permanent Magnet Motors series, featuring a NEMA 42 frame size and dual-channel quadrature encoder, delivering 2700 oz-in holding torque, 90 VDC operation at 3.2 A, and 1800 RPM speed in -40 to 100 C environments.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Conduit Connection (L Configuration)
1/2 NPSC tap with insulating bushing
Conduit Connection (M Configuration)
PG 13.5 tap (no bushing)
Connector Option
MS connector with encoder
Encoder Output
Dual‑channel quadrature with index (Z)
Frame Size
NEMA 42
Front Shaft Diameter (41H, 42H)
0.6250 in (15.875 mm)
Front Shaft Diameter (43H)
0.7500 in (19.05 mm)
Holding Torque per Phase
up to 2700 oz‑in (19.1 Nm)
Max Core Diameter
2.186 ± 0.002 in (55.52 ± 0.05 mm)
Max Length (Model 41H)
5.61 in (142.5 mm)
Max Length (Model 42H)
8.04 in (204.2 mm)
Max Length (Model 43H)
10.56 in (268.2 mm)
Max Operating Temperature (Encoder)
–40 to 100 °C
