SS2000-S40RE\1153MT

by Kollmorgen
$3,296.25 - $3,296.25
$3,296.25
$3,296.25 - $3,296.25
$3,296.25
In Stock, Ships 3 - 5 Days
The SS2000-S40RE\1153MT, engineered by Kollmorgen, epitomizes advanced motion control technology for various international applications. This device operates within an AC voltage range of 90 – 265 V, drawing a nominal current of 0.1 A. Measuring 241 mm × 64 mm × 142 mm (H × W × D) and weighing 1.36 kg, it is designed to control Slo-Syn 2000 stepper motor drives. To ensure safety, it features a protective cover over power connections and requires a flat installation surface with a 2-inch clearance. With an operating temperature range of 0 to +50°C and storage range of -40 to +75°C, the unit meets UL standards and supports up to 95% relative humidity. It includes a grounding screw and 6-pin or 8-pin connectors for signal connection. Available from Servo Supplier, the SS2000-S40RE\1153MT is best handled by trained personnel.
30 Day Warranty
Technical Specifications
  • Manufacturer: Kollmorgen
  • Model: SS2000-S40RE\1153MT
  • Product Type: Oscillator and Analog Speed Follower
  • Rated Voltage: AC 90-265 V
  • Nominal Current: 0.1 A
  • Dimensions (H × W × D): 241 mm × 64 mm × 142 mm
  • Weight: 1.36 kg
  • Operating Temperature Range: 0 to +50 degree Celsius
  • Storage Temperature Range: -40 to +75 degree Celsius
  • Relative Humidity Range: 95%
  • Standards: UL standards
  • Connection Type: 6-pin or 8-pin connector
  • Installation Surface: Flat surface
  • Minimum Clearance: 2 inches
  • Grounding: Screw at the bottom of the module
  • Protection: Protective cover on power connections
  • Application: Controls Slo-Syn 2000 stepper motor drive
  • User: Highly trained staff
