Field power supply
24 Vdc nominal (18–28.8 Vdc)
Function
High-speed counter
Input current
6.1 mA @ 24 Vdc
Input duty range
20–80%
Isolation
Photo-coupler isolation
Maximum input frequency
25 kHz (max, Encoder x4)
Module dimensions
12 × 99 × 70 mm
Off-state threshold
≈7 Vdc / 1.0 mA
On-state threshold
≈12 Vdc / 2.9 mA
Operating altitude
≤2000 m
Operating temperature
-20°C to 55°C
Output current capability
0.5 A per channel
Output type
24 V sink
Relative humidity
5–90% non-condensing
Shock resistance
10G (operating)
Storage temperature
-40°C to 85°C
Supported counting modes
1 Pulse, 2 Pulse, Encoder x1/x2/x4, PWM, Gate
Vibration resistance
2G @ 10–500 Hz
Weight
70 g
