T506-012
by Sanyo Denki
The Sanyo Denki T506-012 is a high-performance servo motor developed by Sanyo Denki as part of the T SANMOTION Servo Motors series. It delivers a rated output of 60 W, a rated torque of 0.19 Nxm, and achieves a maximum rotating speed of 5000 min? for demanding motion control tasks. Designed for industrial automation, this compact motor excels in precision positioning, robotics, and conveyor systems, providing consistent power delivery and responsive operation across dynamic workloads. Its small form factor simplifies integration into existing machinery while maintaining robust performance.
In terms of technical specifications, the T506-012 features an armature inductance of 5.7 mH and an armature winding resistance of 12.1 ?, ensuring smooth current flow and minimal energy loss. The torque constant of 0.183 Nxm/A allows for precise torque generation per ampere of current. Rapid system responsiveness is guaranteed by a short electrical time constant of 0.47 ms, while the thermal time constant of 20 min protects against overheating during sustained operation. With a continuous stall torque of 0.24 Nxm and a mass of just 0.65 kg, this servo motor achieves exceptional torque density and dynamic stability.
Designed for long-term reliability and operational efficiency, the T506-012 operates at a rated armature voltage of 75 V and a rated armature current of 1.2 A. It also endures peak demands with a stall armature current of 1.3 A. The motor’s rated rotating speed of 3000 min? under load supports uniform motion control in diverse industrial environments. Although no explicit certifications are listed, its precise construction and thermal management ensure compliance with stringent industrial standards. Implementing the T506-012 in manufacturing and automation processes enhances system accuracy, reduces maintenance cycles, and improves overall productivity by delivering reliable, high-precision performance.
