T506T-012

The Sanyo Denki T506T-012 servo motor from the T SANMOTION Servo Motors series delivers precision motion control in a compact, rugged package. Featuring a rated output power of 60 W and a rated armature voltage of 70 V, this motor provides a continuous stall torque of 0.20 N·m and achieves a maximum rotating speed of 5000 rpm. It also operates at a rated rotating speed of 3000 rpm under nominal load conditions. The T506T-012 incorporates onboard JOG operation for bench testing without a host controller, complemented by a built-in tachometer generator for real-time velocity feedback. In addition, the motor supports five auto-tuning modes and thirty response levels to match diverse industrial automation requirements.

Technical performance is defined by a collection of critical parameters that ensure stability and responsiveness in demanding applications. The device features an Instantaneous Maximum Torque of 1.2 N·m and a Rated Torque of 0.19 N·m with a Torque Constant of 0.177 N·m/A. Electrical dynamics are governed by an Electrical Time Constant of 0.37 ms and a Mechanical Time Constant of 4.1 ms, while thermal management relies on a Thermal Time Constant of 25 min. The motor’s Friction Torque of 0.020 N·m and Rotor Inertia of 0.0108 ×10^-3 kg·m² contribute to its low inertia design, enabling rapid acceleration and deceleration. The Rated Armature Current of 1.4 A and Voltage Constant of 18.5×10^-3 V·sec/rad complete the suite of key specifications.

Operationally, the T506T-012 excels in environments requiring precise, high-speed control and robust resilience. Its integrated notch filter actively suppresses mechanical resonance for smoother velocity response. The motor operates reliably over an ambient temperature range of 0°C to 40°C and withstands up to 90% relative humidity without condensation. The lead-wire connection style and four mounting holes simplify mechanical integration and electrical hookup. With low rotor inertia and high torsional stiffness, this motor is optimized for tight position control and rapid transient response in continuous duty applications.

System integration is facilitated by compatibility with standard industrial servo drives and configuration software, enabling seamless auto-tuning and real-time monitoring of performance metrics. The T506T-012 is intended for industrial automation applications such as robotics, material handling systems, packaging equipment, and CNC machinery. It is not suitable for residential or nuclear power environments, nor should it be operated under elevated vibration conditions. Proper installation and adherence to the instruction manual ensure safe, reliable operation in demanding production settings.
