T70

Original price $1,515.22 - Original price $1,515.22
Original price
$1,515.22
$1,515.22 - $1,515.22
Current price $1,515.22

In Stock, Ships 1 - 3 Days

The T70 from Kollmorgen features a shaft bore diameter of 70 mm and weighs 8.05 lb. Part of the AKI Interface Panels series, it offers a polar moment of inertia of 0.21120 lb-ft² and uses M20 screws. The device supports a transmittable torque of 5,163 ft-lbs and an axial force rating of 35,518 lbf.

The sleeve diameter is 90 mm with a sleeve length of 85 mm. It features a flange diameter of 140 mm. It transmits a transmittable radial force of 2,922 lbf.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Actuation Screws


M20

Dimension (d2)


149 mm

Flange Diameter (d1)


140 mm

Hub Bore Tolerance Grade


H7

Overall Length (l1)


110 mm

Polar Moment Of Inertia


0.21120 lb-ft²

Shaft Bore Diameter (d)


70 mm

Shaft Tolerance Grade


h8

Sleeve Diameter (d)


90 mm

Sleeve Length (l)


85 mm

Tightening Torque


30 ft-lbs

Transmittable Fa


35,518 lbf

Transmittable Fr


2,922 lbf

Transmittable T


5,163 ft-lbs

Weight


8.05 lb
