T730-012

The Sanyo Denki T730-012 servo motor from the T SANMOTION Servo Motors series by Sanyo Denki is engineered to deliver high-performance motion control in compact industrial applications. It combines a rated output of 0.3 kW with a motor flange size of φ76 mm, offering a balance of power density and installation convenience. Featuring a peak stall torque of 9.8 N·m and a continuous stall torque of 1.43 N·m, the T730-012 excels at handling sudden load increases without compromising stability. Its small form factor and robust design make it ideal for factory automation systems, packaging equipment, and precision assembly machinery. This model includes a key-type output shaft and an IP43-rated housing to ensure reliable mechanical coupling and protection against spray and solid ingress.

Detailed technical specifications underline the T730-012’s engineering precision. The motor’s rated armature voltage of 75 V and rated speed of 2500 min-1 provide a consistent baseline for speed-torque profiling. Its rotor inertia of 2.7 × 10⁻⁴ kg·m² supports rapid acceleration and deceleration cycles, while the servo motor mass of 2.5 kg contributes to a favorable power-to-weight ratio. The unit delivers its torque via an output shaft with key and features a lead wire connection terminated in a generous lead wire length of 1000 mm for flexible wiring layouts. Absence of an oil seal and a tachometer generator simplifies internal construction and enhances maintainability. The motor is backed by a one-year warranty to ensure long-term reliability in demanding industrial environments.

Operational features highlight the T730-012’s capability to tackle variable workloads and installation constraints. The combination of continuous stall torque of 1.43 N·m and peak stall torque of 9.8 N·m provides a wide dynamic range for both constant-speed processes and intermittent high-torque events. Its IP43 protection rating offers defense against dust ingress and water spray, making it suitable for standard shop-floor conditions. The key-type shaft interface ensures secure mechanical engagement with couplings, gearboxes, or belt pulleys. A 1000 mm lead wire length grants extra freedom for routing and connector placement. Maintenance requirements are minimized by the omission of an oil seal and tachometer, focusing on core performance elements.

System integration is streamlined by the T730-012’s compatibility with common industrial servo drives and controllers. The φ76 mm flange and keyed shaft facilitate drop-in replacement or incremental upgrades within automation cells. Its compact design and standardized mounting bolt pattern simplify retrofits in packaging lines, conveyor systems, and pick-and-place robots. Ideal for applications where precise torque control, rapid response, and moderate protection are critical, the T730-012 drives productivity in industrial automation, laboratory equipment, and food processing machinery.
