S image of T730T-012EL8N

T730T-012EL8N

by Sanyo Denki
$1,875.00 - $2,947.21
$1,875.00
$1,875.00 - $2,947.21
$1,875.00

The Sanyo Denki T730T-012EL8N from the T SANMOTION Servo Motors series is a high-precision Servo Motor designed for industrial automation. It delivers 300 W of rated output and a rated torque of 1.18 Nm, with a continuous stall torque of 1.43 Nm at 2500 min-1. Operating on 75 V and 5.2 A, it features a torque constant of 0.273 Nm/A and reaches up to 4000 min-1 with a peak torque of 9.8 Nm. The rotor inertia is 0.270×10^-3 kg·m², friction torque 0.05 Nm, and feedback is via an incremental encoder (PP031) with 1000 P/R resolution under IP43 protection.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Continuous Stall Torque

1.43 Nm.

Encoder

Incremental encoder (PP031) with 1000 P/R

Friction Torque

0.05 Nm.

Instantaneous Maximum Armature Current

40 A

Instantaneous Maximum Torque

9.8 Nm.

Maximum Rotating Speed

4000 min⁻¹

Rated Armature Current

5.2 A

Rated Armature Voltage

75 V

Rated Output

300 W

Rated Rotating Speed

2500 min⁻¹

Rated Torque

1.18 Nm.

Rotor Inertia

0.270×10⁻³ kg·m²

Stall Armature Current

5.5 A

Torque Constant

0.273 Nm./A

Voltage Constant

28.6×10⁻³ V/min⁻¹
