C image of TDM 1.2-030-300-W1-000 | Main (Front Left)

TDM 1.2-030-300-W1-000

by Bosch Rexroth Indramat
$2,913.48 - $2,913.48
$2,913.48
$2,913.48 - $2,913.48
$2,913.48

In Stock, Ships 1 - 3 Days

The TDM 1.2-030-300-W1-000, a servo drive brought to you by Bosch Rexroth Indramat, operates primarily as a variable speed drive with a predetermined maximum speed. This model 2 drive displays a capacity for brief, high acceleration moments. It comes with a built-in fan for cooling and safely operates between +5°C to +45°C. Features include a 30A current rating, 300VDC circuit voltage, and a 9kW power rating. Connection terminals X5 and X6 are available for user input/output and MAC motor feedback respectively. The unit can also function as a torque-controlled, master-slave or tandem drive. Conforming to DIN VDE 0110 specifications, the drive has Class C insulation with an IP 10 protection degree, all neatly enclosed in a sealed housing unit. Ideal for use with MAC 71 to MAC 160 three-phase motors, it is perfect for automation industries.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Servo Drive

Model

TDM 1.2-030-300-W1-000

Configuration

Model 2

Type Current Rating

30A

Minimum Adjustable Current

15A

Link Circuit Rated Bus Voltage

300VDC

Power Rating

9kW

Cooling Method

Forced Ventilation (Built-in Fan)

Ambient Operating Temperature

+5°C to +45°C

High Temperature Indicator

Red colored TS LED Flashing

Terminal X5

User Input or User Output connection

Terminal X6

Feedback Connection for MAC motor

Torque Control

Yes

Functioning Modes

Master-Slave Drive or Tandem Drive

Insulation Category

Class C (DIN VDE 0110 spec)

Degree of Protection

IP 10

Encasement

Completely Sealed Cabinet

Dimensions

Base Height: 355mm, Ventilating Air Inlet and Outlet: 80mm at top and bottom

Intended Motor Usage

MAC 71 to MAC 160 range of three-phase synchronous servomotors
