P image of TDM 2.1-030-300-W0

TDM 2.1-030-300-W0

by Bosch Rexroth Indramat
$1,899.80 - $9,861.74
$1,899.80
$1,899.80 - $9,861.74
$1,899.80
The TDM 2.1-030-300-W0 is a servo drive module from Indramat’s second TDM series. It features a 30A type current and link circuit rated voltage of 300 (± 15%) DC V. The module classifies as type 1 with tacho feedback and no incremental encoder as per MAC motor feedback unit. This module benefits from natural convection cooling and bears Indramat’s specified motor-amplifier combustion code 030 and input weighting code 300. Power specifications include a 30A current and peak, a continuous 25A current, 9kW power and 160W power loss. Fan connection supply voltages are 220 or 115V at frequencies of 50 - 60 Hz. Operation temperatures range from +5⁰C - +45⁰C, maxing out at 55⁰C when operated at reduced rated data. Storage and transport accommodate between -30⁰ to +85⁰ temperatures. Sea-level safe up to 1000m when operating at reduced data rates, boasting a humidity classification of F, insulation category C, and protection category IP 10. It weighs 9kg.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product Series

TDM 2.1

Type Current

30A

Link Circuit Rated Voltage

300 (± 15%) DC V

Classification According to Feedback Unit

1 (tacho feedback, without incremental encoder)

Motor Cooling System

Natural Convection

Motor and Amplifier Combustion Code

030

Input Weighting Code

300

Peak Current

30A

Continuous Current

25A

Power

9kW

Power Loss

160W

Supply Voltage of Fan Connection

220 or 115V

Frequency of Fan Connection

50 - 60 Hz

+24V Load Voltage Current Consumption

750 [350]

+15V Measuring Voltage Current Consumption

140mA

-15V Measuring Voltage Current Consumption

60mA

Operation Ambient Temperature (with Rated Data)

+5⁰C to +45⁰C

Operation Ambient Temperature (with Reduced Rated Data)

55⁰C

Storage and Transport Temperature

-30⁰C to +85⁰C

Mounting Altitude (maximum)

1000m above sea level

Humidity Classification

F (DIN 40 040)

Insulation Category

C (DIN VDE 0110)

Protection Category

IP 10 (DIN 40 050)

Weight

9kg
