TPA/1-15885-602-5306B5

The Kollmorgen TPA/1-15885-602-5306B5 is a precision direct-drive motor from the Inland Direct Drive Motors series by Kollmorgen, engineered to deliver exceptional performance in demanding industrial environments. This zero-contact, zero-maintenance brushless design operates with 3-phase sinusoidal commutation to ensure smooth torque delivery and reduced acoustic noise. The motor provides a continuous force range of 175 N to 5341 N and a peak force capability from 405 N to 12,726 N, making it suitable for both low-load precision tasks and high-force applications. Its stainless-steel magnet covers offer robust protection against contaminants and mechanical wear, while a standard coil assembly mass delivers a balance of inertia and responsiveness. Rated for operation at an ambient temperature of 25 °C, the unit maintains consistent performance across controlled factory settings.

Performance characteristics of the TPA/1-15885-602-5306B5 are optimized for rapid, precise positioning. The integrated anti-cogging mechanism minimizes torque ripple, delivering minimal cogging and high positional resolution for ultra-smooth motion profiles. High force density in conjunction with easily achievable peak acceleration above 10 G enables rapid start-stop cycles and reduced settling times. The motor’s very low settling time and high position accuracy and resolution support sub-micron positioning repeatability, critical for semiconductor manufacturing and assembly tasks. Thermal management is enhanced by low thermal losses and dual-sensor protection with PTC and KTY84-130 devices, ensuring safe operation under sustained high-load conditions.

Designed for seamless integration into automated systems, the Kollmorgen TPA/1-15885-602-5306B5 features a robust voltage isolation system rated at 480 VAC, safeguarding both control electronics and operators. Its brushless, zero-maintenance architecture reduces downtime and running costs, while low heat dissipation simplifies cooling requirements. The motor’s resilience and reliability make it ideal for robotics, CNC machinery, and industrial automation platforms requiring continuous-duty operation. With peak force performance, advanced thermal protection, and easy interfacing, this direct-drive motor delivers a turnkey solution for high-precision motion control applications.
