TTB2-2042-3052-A

The TTB2-2042-3052-A from Kollmorgen represents a high-performance solution within the Inland Direct Drive Motors series, delivering precision motion control without the need for mechanical transmission components. This Brushless Direct Drive Motor features a robust Aluminum housing and a Frame size of 204 mm, ensuring durability and compatibility with varied industrial setups. Capable of achieving a Peak torque of 305 Nm and maintaining a Continuous torque of 102 Nm, this motor excels in applications demanding both power and precision. Designed for 480V AC operation, the unit operates across a Speed range of 0–1000 RPM to meet dynamic performance requirements. With a compact mass of 25 kg and a Protection rating of IP65, it offers exceptional power density in challenging environments.

Technical capabilities are at the core of the TTB2-2042-3052-A’s design, beginning with its Continuous current rating of 14 A and Peak current capacity of 42 A, providing a broad operating envelope for varied loads. The integrated High-Resolution Feedback encoder delivers precise position data for accurate closed-loop control, while the motor’s Brushless configuration ensures minimal maintenance and long service life. The aluminum housing enhances heat dissipation and structural stiffness, supporting the motor’s Operating temperature range of -20°C to 40°C. A natural convection Cooling method further simplifies installation by eliminating external cooling systems. Together, these features enable high torque output and swift speed transitions with consistent performance.

Operational reliability and ease of use define the next layer of benefits. The IP65 Protection rating ensures full protection against dust and low-pressure water jets, allowing operation in harsh industrial environments without compromise. Natural convection cooling reduces downtime and maintenance costs by removing the need for additional fans or liquid cooling loops. With a compact footprint and a weight of only 25 kg, the motor integrates seamlessly into space-constrained systems while maintaining structural resilience. The high torque-to-weight ratio boosts energy efficiency and supports sustained heavy-duty cycles, making it ideal for frequent start-stop operations and continuous-duty applications.

Integration flexibility and broad applicability make the TTB2-2042-3052-A an ideal choice for modern automation challenges. Its direct-drive architecture eliminates backlash and mechanical wear associated with gearboxes, improving precision in CNC machinery, robotic arms, rotary tables, and indexing systems. The motor’s 480V AC compatibility and natural convection cooling streamline system design and reduce ancillary equipment requirements. Whether deployed in packaging lines, semiconductor manufacturing, or industrial automation cells, the Kollmorgen TTB2-2042-3052-A combines compactness, reliability, and high torque output to meet the rigorous demands of today’s automated processes.
