TVD 1.3-15

Request a quote
The Bosch Rexroth Indramat TVD 1.3-15 is a power supply module designed for direct mains connections. It belongs to the TVD series with series 1 and design 3. This module offers a continuous power of 15 kilowatts at a DC bus voltage of 320 volts. The TVD 1.3-15 accommodates auxiliary devices such as mains supply modules, capacitances, commutating chokes, DC bus smoothing chokes and auxiliary bleeder modules. It measures 150mm in width, 325mm in height, and 355mm in depth and maintains recommended air flow for cooling by suggesting a minimum of 80mm spacing on each side. Ambient temperature for operation should be between 5-45 degrees Celsius, with an output derating at higher temperatures, and the module supports brief peak DC power of 45 kilowatts. Weighing 11.2 kilograms, this power supply operates within an input voltage range of 380-480 volts AC and a frequency range of 50-60 Hertz.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product: TVD 1.3-15 Power Supply Module
  • Series: 1
  • Design: 3
  • Rated DC Bus Continuous Power: 15 kilowatts
  • Rated DC Bus Voltage: 320 Volts
  • Auxiliary Devices: Mains supply modules, capacitances, commutating chokes, DC bus smoothing chokes, auxiliary bleeder modules
  • Dimensions: 150 millimeters width, 325 millimeters height, 355 millimeters depth
  • Recommended Spacing for Cooling: 80 millimeters
  • Recommended Operating Temperature: 5 to 45 degrees Celsius
  • Output Derates: 80% at 55 degrees Celsius, 65% at 5000 meters above sea level
  • Peak DC Power (0.3 seconds): 45 kilowatts
  • Bleeder Peak Power: 40 kilowatts
  • Bleeder Continuous Power: 1 kilowatt
  • Shipping Weight: 11.2 kilograms
  • Input Voltage Range: 380 to 480 Volts AC
  • Input Frequency Range: 50 to 60 Hertz
  • Input Power Rating: 300 VA
