P image of TVD 1.3-15-03-S100

TVD 1.3-15-03-S100

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
Designed and manufactured by Rexroth Indramat, the TVD 1.3-15-03-S100 is a power supply module that stands out in the realm of motion control products. Its high efficiency, cost-effectiveness, durability, and adaptability are standout features, ensuring it meets all your module needs including servo drives, supply modules, servo motors and more. To maintain optimum performance, it's essential to consider its ambient conditions: peak mounting height up to 1000m above sea level, relative humidity at 95%, absolute humidity at 25g H2O/m3 air, and ambient temperatures between +5 to +550C. It features an input voltage of 3 x 380 to 480 +/- 10% V, a frequency of 50 to 60 Hz, and DC bus voltage of 320 +/-5% V. Maximum DC power is 45kW, continuous DC power is 15 kW and bleeder continuous power stands at 1 kW. Maximum power without bleeder loss is 330kw, with regenerated energy of up to 60 Kws and mass at 11.2 kg.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Rexroth Indramat

Product type

Motion Control Products

Product

TVD 1.3-15-03-S100 Power Supply Module

Peak Mounting Height

1000 meter above sea level

Ideal Relative Humidity

95%

Ideal Absolute Humidity

25g of water/m3 Luft

Transport Temperature

-30 to +850C

Ambient Temperature (Rated Data)

+5 to +45OC

Ambient Temperature (Derated Data)

+550C

Input Voltage

3 x 380 to 480 +/- 10% V

Frequency

50 to 60 Hz

DC Bus Voltage

320 +/-5% V

Maximum DC Power (0.3 s)

45 kW

Continuous DC Power

15 kW

Bleeder Continuous Power

1 kW

Power Dissipated

330kw

Maximum Regenerated Energy

60 Kws

Mass

11.2kgs
