U508-102E17
by Sanyo Denki
The U508-102E17 from Sanyo Denki is a high-performance unit within the Super DC Servo Motors series, designed for precision motion control in demanding industrial environments. This motor operates at an Operating Voltage of 75V DC and draws a Rated Current of 1.7 A, delivering consistent power for continuous operation. It features a robust Flange mounting design that simplifies integration into existing machinery and ensures mechanical stability. With a Rated Speed of 3000 RPM, the U508-102E17 combines compact form factor and reliable output, making it ideal for automation and robotics. The motor’s Protection Class IP20 rating and Air-cooled system maintain safe operation while preserving core temperatures under strenuous workloads. Its internal identifiers, including Internal Model Code 01MAN86485-G002 and Manufacturer Identifier BP5281, guarantee traceability and streamlined maintenance.
Performance characteristics of the U508-102E17 are defined by its triple feedback channels m —Channels: CH.A, CH.B, CH.C—providing real-time positional data to drive controllers with high resolution and accuracy. The motor achieves Resolution of 500 ppr for fine-grained motion adjustments and crisp trajectory control. Its Temperature Range of -10C to +70C and a Maximum Operating Temperature of 50C highlight its ability to sustain stable performance across varied industrial climates. The three-phase architecture ensures smooth torque delivery and reduces ripple currents, enhancing responsiveness in high-speed motion profiles. Attention to detail in internal winding design and thermal management optimizes efficiency, while the sturdy M-80 Series construction underpins a long service life with minimal downtime.
Engineered for reliability and seamless integration, the U508-102E17 excels in applications such as factory automation, conveyor systems, and robotic arms where precision and uptime are critical. The Flange mounting interface aligns quickly with gearboxes, couplings, or direct-drive assemblies, reducing installation costs and mechanical complexity. Its IP20 protection and air-cooled operation support safe deployment in enclosed control cabinets or open machinery frames. Coupled with Sanyo Denki’s advanced servo drives, the motor enables sophisticated motion algorithms, including torque compensation and electronic damping. From pick-and-place systems to CNC indexing tables, the U508-102E17 delivers consistent accuracy, robust thermal performance, and the flexibility required for next-generation industrial automation.
