VAC-YMF22-18.5R-153KR6

by Okuma
Original price $13,096.00 - Original price $13,096.00
Original price
$13,096.00
$13,096.00 - $13,096.00
Current price $13,096.00
In Stock, Ships Today
Request a quote
The VAC-YMF22-18.5R-153KR6 is a high-performance, 3-phase AC spindle motor manufactured by Okuma, a notable Japanese expert specializing in industrial automation technology. As part of the VAC series, this industry-grade spindle motor possesses 4 poles, provides a consistent power rating of 18.5 kW and peaks at 22 kW for a duration of 30 minutes. It operates at a nominal speed of 1,500 RPM, which can extend up to 6,000 RPM. The motor connects at 170 V and draws peak and continuous currents at 112 A and 99 A, respectively. Its drive unit, the DD2A/1104, houses LEDs for operational indications and diagnostic measures. Conforming to NEMA's insulation class F specifications, it can withstand an ambient temperature range of 0o to 40o C and supports a maximum winding insulation temperature of 155oC. The motor is resistant to damage from oil, water and harmful chips.
30 Day Warranty
Technical Specifications
  • Manufacturer: Okuma
  • Product Type: AC Spindle Servo Motor
  • Series: VAC
  • Model: VAC-YMF22-18.5R-153KR6
  • Phases: 3-phase
  • Poles: 4 poles
  • Nominal Speed: 1500 RPM
  • Max Speed: 6000 RPM
  • Continuous Power: 18.5 kW
  • Peak Power: 22 kW
  • Drive End Bearing Code: 6311M2ZZ
  • Non-drive End Bearing Code: 6210MZZ
  • Voltage: 170 V
  • Peak Current: 112 A
  • Continuous Current: 99 A
  • Insulation Class: F
  • Max Winding Temp: 155oC
  • Optimal Ambient Temp: 0o C to 40o C
  • Drive Unit: DD2A/1104
  • LED Indicators: Yes
  • Protection from Chips, Water, Oil: Yes
