manufacturer image of VAC5-D22

VAC5-D22

by Okuma
$9,093.33 - $9,093.33
$9,093.33
$9,093.33 - $9,093.33
$9,093.33
Available, Shipping Varies
The Okuma manufactured VAC5-D22 is an industrial servo drive, designed to operate with three distinct power ratings: 18.5 kilowatts, 22 kilowatts, and 30 kilowatts. To facilitate these, respectively, this necessitates a supply connection capable of delivering 28, 33, or 45 kVA power outputs. Important to note are stipulated the precautions, including power disconnection and discharge, correct power supply specifications, input/output connection inspection, sufficient grounding, protective device (like fuses or circuit breakers) implementation, and appropriate control cabinet usage as well as a thermostat for temperature regulation. This upgraded version of the VAC3-22 model comes with an optical interface for NC communication and can withstand up to 0.5G vibrations. For optimum performance, maintain working ambient temperatures of 0-55 degrees Celsius and control cabinet temperatures of 0-45 degrees Celsius, with storage temperatures maintained between -20 and 60 degrees Celsius.
30 Day Warranty
Technical Specifications
  • Manufacturer: Okuma
  • Product Type: Industrial Servo Drive
  • Model Number: VAC5-D22
  • Interface: Optical Interface for NC communication
  • Supported Power Ratings (For Motor): 18.5 kilowatts, 22 kilowatts, 30 kilowatts
  • Supply Needs (For 18.5 kilowatts Output): 28 kVA power output
  • Supply Needs (For 22 kilowatts Output): 33 kVA power output
  • Supply Needs (For 30 kilowatts Output): 45 kVA power output
  • Operating Ambient Temperature: 0 to 55 degrees Celsius
  • Control Cabinet Ambient Temperature: 0 to 45 degrees Celsius
  • Storage Temperature Range: -20 to 60 degrees Celsius
  • Vibration Tolerance During Operation: maximum 0.5G
  • Predecessor Model: VAC3-22 from VAC3 series.
