VACON0100-3L-0016-5-FLOW+SBF4+IP54+FL02+DPAP+DLDK
by Danfoss
The VACON0100-3L-0016-5-FLOW+SBF4+IP54+FL02+DPAP+DLDK drive from Danfoss stands as a robust solution within the VACON 100 Industrial Drives family, engineered to deliver high-performance motor control in demanding industrial settings. Rated for a Continuous Output Current (110% Load) of 16 A and supporting a Motor Power At 400v of 7.5 kW (10 HP at 480v), this drive accommodates a wide range of machinery requirements. It accepts a 380-500 VAC 3-phase Input Voltage and operates across an Input Frequency band of 50-60 Hz, ensuring compatibility with global power networks. Compact yet powerful, the unit integrates seamlessly into control panels thanks to its standardized Frame Size MR5 and optimized thermal design. Designed and manufactured by Danfoss, this model sets the benchmark for efficiency and reliability in industrial automation.
Featuring advanced technical capabilities, the drive’s Drive Series designation of VACON 100 FLOW indicates its specialized airflow-cooled topology for improved heat dissipation. The Max Output Current (2s) of 24 A provides a significant short-term overload capacity, allowing handling of transient torque demands without tripping. Communication versatility is ensured by built-in support for Fieldbus Protocols including Modbus, N2, and BacNet, enabling seamless integration with PLCs and building management systems. The optional factory-fitted I/o Board Factory Option F4 adds a versatile 2-relay board with thermistor inputs for real-time thermal monitoring and enhanced protection. By incorporating these features, the drive delivers precise, real-time control over motor dynamics and process variables.
Operational excellence is maintained through its Enclosure Protection rating of IP54/NEMA 12, guarding against dust ingress and water spray while permitting installation in less controlled environments. Classified under Environment Class C2 Commercial & Industry, the drive tolerates typical industrial contaminants and ambient conditions. The intuitive Graphical Keypad MK01 simplifies configuration, diagnostics, and local monitoring, reducing commissioning time and maintenance costs. With continuous output capability at 110% load, coupled with a Max Output Current headroom, the system assures stable operation under variable loads and transient events. These attributes combine to minimize downtime and maximize production throughput.
Integration into complex automation architectures is facilitated by its broad Input Voltage compatibility (380–500 VAC) and flexible Fieldbus Protocols, enabling engineers to tailor network topologies to specific application needs. Its compact Frame Size MR5 housing conserves panel space, while the drive’s robust design supports installation in conveyor systems, pump and fan control, HVAC operations, and other heavy-duty machinery. By leveraging the integrated relay board option and advanced thermal management, users can deploy the VACON0100-3L-0016-5-FLOW+SBF4+IP54+FL02+DPAP+DLDK drive as a plug-and-play component in both new installations and retrofit upgrades, ensuring rapid time-to-market and sustained operational efficiency.
