S image of VAM41.1-PB-NA-NN-TA-VB-BA-1608-NN

VAM41.1-PB-NA-NN-TA-VB-BA-1608-NN

by Bosch Rexroth Indramat
$1,095.63 - $6,621.50
$1,095.63
$1,095.63 - $6,621.50
$1,095.63

In Stock, Ships Fast

The Bosch Rexroth Indramat VAM41.1-PB-NA-NN-TA-VB-BA-1608-NN is a machine operator terminal from the VAM41 series. It's designed for operating and controlling industrial machinery. It features a 4-stage key switch, 15 illuminated keys, an E-STOP button, two override switches and various digital input and output connectors. It weighs around 1,380 grams, has a mounting cut of 375 x 178mm and an 80mm installation depth. It utilizes a 24VDC PELV logic voltage and has a power consumption limit of 1.7A. The terminal also houses eight digital 24V outputs and 16 digital 24V inputs. It comes with eight cutouts for indicator and control unit installation. The device's maximum vibration range is 3.50mm amplitude between 5 and 9Hz and is both CSA Certified and UL Listed. It has to be stored within a temperature range of -25°C and +75°C. Approved accessories and replacements must be manufacturer-approved.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Series

VAM41

Key Switch

4-stage key switch

Keypad

15 illuminated keys

Switches

2 override rotary switches and an E-STOP pushbutton

Connectors Count

2

Digital inputs and outputs

Yes

Use

Operating various control units in machines

Mounting Cut

375 x 178mm (W x H)

Installation Depth

80mm

Weight

1380 grams

Width

equivalent to the width of the manufacturer’s BTV 40 operator terminal

Digital Outputs

8 digital 24V outputs

Digital Inputs

16 digital 24V inputs

Cutouts Count

8

Power Consumption

1.7A

Logic Voltage Supply

24VDC PELV

Connection Cross-section

2 x 16 AWG

Vibration

3.50mm amplitude maximum vibration between 5 and 9Hz

Approval

CSA Certified and UL Listed

Wire Type

60/75°C copper and Class 1 or equivalent wires

Storage Temperature

-25°C and +75°C
