P image of VCP08.2DTN-003-NN-NN-PW

VCP08.2DTN-003-NN-NN-PW

by Bosch Rexroth Indramat
$2,575.58 - $2,575.58
$2,575.58
$2,575.58 - $2,575.58
$2,575.58

In Stock, Ships Fast

The VCP08.2DTN-003-NN-NN-PW is a highly versatile and robust operator terminal produced by Bosch Rexroth. Part of the renowned VCP series, it supports integration with both serial bus and Fieldbus interfaces. Suited to various applications, the terminal allows users to activate machine functions via a 39-key membrane keyboard. To aid operation, 15 status LEDs are included. Compatibility extends to the DeviceNet and PROFIBUS DP interfaces with isolated interface slots. Powered by a 200 MHz RISC ARM9 CPU with a real-time clock, a watchdog timer, and battery monitor, the terminal has ample memory options, including 512KB SRAM and SDRAM and an additional 3MB application memory backed by 16MB flash memory. Connections are simple thanks to D-SUB, Phoenix COMBICON, RJ45 female, and USB female connectors. This energy-efficient model consumes just 0.25 A of current at 24 V supply, with a connected load of 6W. The FSTN display offers comfortable viewing with temperature-compensated contrast, a 30,000-hour half-life backlight, and a 320x240 pixel resolution which displays in five shades of grey.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth

Product Line

VCP Series

Product Model

VCP08.2DTN-003-NN-NN-PW

Terminal Type

Compact Operator Terminal

Interface Support

Serial Bus, Fieldbus

Install Position

Any Position

Input Method

39 Key Membrane Keyboard

Status Indicators

15 LEDs

Interface Types

DeviceNet, PROFIBUS DP

CPU

RISC ARM9

CPU Clock Frequency

200 MHz

Additional CPU Functions

Real-time clock, Watchdog timer, battery monitoring

Memory

SRAM and SDRAM: 512 KB, Application: 3MB, Flash: 16MB

Connectors

D-SUB, Phoenix COMBICON, RJ45 female, USB female

Power Supply

24 V

Current

0.25 A

Connected Load

6 W

Power Consumption

Max 0.35 A

Display Size

57.6 mm x 76.8 mm

Display Type

FSTN

Display Features

Temperature compensated contrast, Backlighting half-life: 30,000 hours

Resolution

320 X 240 Pixels

Colors

5 Shades of Gray.
