VCP11.2DWN-003-SR-NN-PW

Original price $5,500.00 - Original price $5,500.00
Original price
$5,500.00
$5,500.00 - $5,500.00
Current price $5,500.00
In Stock, Ships 1 - 2 Days
Request a quote
The VCP11.2DWN-003-SR-NN-PW model, offered by Bosch Rexroth, is a versatile machine operator terminal designed for control tasks in various applications like assembly systems, packaging machines, and machine tools. Encased in a robust assembly of galvanized steel, anodized aluminum, and polyester foil, the terminal boasts an IP20 protected rear and can resist solid particles and low-pressure water jets on the front. This lightweight model, at 500 grams, offers flexible mountings depending on user requirements. Key features include a 3.8 inches touch-screen FSTN display, DC 24V electrical connection, and reverse polarity protection. Driven by a RISC ARM9 CPU with a 200 MHz clock frequency, it houses 3MB of application memory, 16MB flash, 32MB SDRAM, and 512kB SRAM. Communication capabilities include RS485, RS232, and Ethernet interfaces. The device can function within a temperature range of +5 to +45 ͦC and up to 85% relative humidity, surviving vibrations of 10 Hz to 150 Hz and can be installed up to 2,000 meters above sea level.
30 Day Warranty
Technical Specifications
  • Product Name: Bosch Rexroth Small Operator Terminal
  • Model: VCP11.2DWN-003-SR-NN-PW
  • Weight: 500 grams
  • Mounting: Any desired position
  • Front Side Protection: Against solid particles and low-pressure water jets
  • Rear Side Protection: IP 20 standard
  • Material: Galvanized steel, anodized aluminum, polyester foil
  • Electrical Connection: DC 24V via connector X1
  • Screen: 3.8 inches touch-screen FSTN display
  • CPU: RISC ARM9, 200 MHz clock frequency
  • Memory: 3MB application memory, 16MB flash, 32MD SDRAM, 512Kb SRAM
  • Interfaces: RS485, RS232, Ethernet
  • Ambient Temperature for Operation: +5 to +45 ͦC
  • Relative Humidity: 85% maximum
  • Installation Altitude: Up to 2000 meters above sea level
  • Vibration Frequency: 10 Hz to 150 Hz (DIN EN 60068-2-6)
  • Firmware: Preloaded
