VDP40.3DFN-D1-NN-NN

Original price $10,338.75 - Original price $10,338.75
Original price
$10,338.75
$10,338.75 - $10,338.75
Current price $10,338.75
In Stock, Ships Today
Request a quote
The Bosch Rexroth Indramat VDP40.3DFN-D1-NN-NN is a high-tech operator panel with dual input functionality. It boasts a 15” TFT display that supports 16 million colors with a resolution of 1024 x 768. This operational interface integrates IndraControl VAK keyboard featuring 14 supplementary keys, along with 16 each of function and machine keys. The panel is equipped with various status LEDs, including Universal Power Supply (UPS), temperature, hard disk, and voltage indicators. This model also includes an array of interface ports such as 1 front USB, 4 rear USB, and 1 CDI. Its working conditions range from 5 ᵒC to 45 ᵒC. The device measures 370 mm in width, 407 mm in height, and 60 mm in depth, and weighs 5 kg. Its IP 54 standard ingress protection makes it dust-resistant and virtually impervious to water splashes. This efficient panel demands only 35W power and operates at a 24 V DC supply.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Operating Panel
  • Display Type: TFT
  • Display Colors: 16 million
  • Display Size: 15"
  • Display Resolution: 1024 x 768
  • Keyboard Type: IndraControl VAK
  • Keyboard Features: 14 additional keys, 16 function keys, 16 machine keys
  • Status LEDs: UPS, temperature, hard disk, voltage
  • Interfaces: 1 front USB, 4 back USB ports, 1 CDI interface
  • Weight: 5 kg
  • Operating Temperature Range: 5 ᵒC – 45 ᵒC
  • Ingress Protection: IP 54
  • Power Consumption: 35 W
  • Power Supply: 24 Volts DC
  • Dimensions: 370 mm x 407 mm x 60 mm.
