manufacturer image of VEP40.4DBN-512NN-MAD-1G0-NN-FW

VEP40.4DBN-512NN-MAD-1G0-NN-FW

by Bosch Rexroth Indramat
Request a quote
The VEP40.4DBN-512NN-MAD-1G0-NN-FW is an embedded terminal built by Bosch Rexroth Indramat. It features a ready contact located on pins 4 and 5 of its X1S connector which indicates the operational status of the device. It is critical not to exceed the switching capacity of this ready contact. With dimensions of 290mm height and 350mm width, the device requires cables with strain relief for connection. It should ideally be mounted on a level surface with a matching cutout and secured using the nuts behind the mounting bolts. A metallic coupling or connector housing with a large shield area is recommended. The device uses an Intel Celeron processor with a clock frequency of 600MHz. Status and errors are displayed via four LEDs on the front panel. It functions optimally when the compact flash card utilization is below 70%. Be cautious of a blue screen or freezing, as this might cause data loss and erratic machine behavior. Its type plate at the back contains essential servicing information.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Embedded Terminal
  • Product Code: VEP40.4DBN-512NN-MAD-1G0-NN-FW
  • Height: 290mm
  • Width: 350mm
  • Connector: X1S connector with ready contact
  • Switching Capability: Not to be exceeded
  • Strain Reliefs: Required on connecting cables
  • Mounting Requirements: Even surface, appropriate-sized cutout, nuts behind mounting bolts
  • Suitable Coupling or Connector Housing: Conductive and metallic with large-area shield support
  • Processor: Intel Celeron, 600MHz clocking frequency
  • Indicators: Four LEDs on front panel; Green for normal operation, OFF for no 24VDC supply voltage
  • Memory Limitations: Reduced performance at over 70% compact flash card utilization
  • Warnings: Data loss and uncontrolled movements possible if blue screen or device freezing occurs
  • Servicing: Type-plate on rear with useful details
