VT 12352-32/1
The Bosch Rexroth Indramat VT 12352-32/1, part of the VT 1600 Servo Amplifiers series and manufactured by Bosch Rexroth Indramat, delivers precision motion control with robust electrical characteristics. This amplifier supports a Power Supply Voltage of ±15 V (E0) or ±22 V to ±28 V (E1) and draws under Power Supply Current of 200 mA, ensuring efficient low-power operation. Its configurable Output Current ranges from ±60 mA to ±100 mA, while the integrated Dither Current of 3 mApp at 340 Hz minimizes mechanical resonance. The unit weighs just 0.33 lb (0.15 kg) and adheres to Card Dimensions of 100 × 160 mm (Eurocard, DIN 41 494), featuring a Front Plate Dimensions of 3U height and 8 HP width for seamless rack integration. Compatible with industrial automation environments, it offers reliable performance within tight space constraints.
Performance is enhanced through precise control handling, accepting an Internal Control Voltage from 0 to ±10 V for versatile interfacing with diverse control systems. The amplifier provides adjustable Signal Gain settings from 0.5 to 10, enabling fine-tuning of system sensitivity and dynamic response. Its robust relay interface utilizes a Relay Coil Resistance of 2000 Ω, operates at Relay Coil Voltage of 22 V to 28 V, and maintains a Relay Duty Cycle of 1 ms for rapid switching tasks. With Environmental Resistance rated at IP20, the module is protected against solid objects ≥12 mm while permitting adequate ventilation for heat dissipation. The ultra-compact footprint and low weight streamline installation in Eurocard slots, and the digital dither feature ensures smooth actuator control under varying loads.
Designed for dependable operation across a wide temperature range, the VT 12352-32/1 supports Storage Temperature extremes from -20 °C to 70 °C and functions reliably between -20 °C and 70 °C in ambient conditions. Its Warranty of one year covers manufacturing defects, assuring maintenance cost control and uptime. Weighing only 0.33 lb, it integrates effortlessly into industrial automation cabinets, minimizing structural load. With Eurocard compliance and Bosch Rexroth Indramat quality, this amplifier serves in diverse applications such as CNC machinery, robotics, packaging systems, and conveyor drives, where precise current regulation and compact design are paramount.
