Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Biasing current
10 to 300 mA, adjustable via potentiometer
Card dimensions
100 x 160 mm (Euro-card DIN 41494)
Clock frequency
100/200 Hz ±10%
Connector
32-pin male, DIN 41612 Form D
Current consumption
<1 A
Front panel height
128.4 mm (3 HE)
Front panel width (component side)
15.24 mm (3 TE)
Front panel width (soldering side)
5.08 mm (1 TE)
Fuse rating
2.5 A time-delay
Input 1 range
0 to 9 V (ref. M0)
Input 2 diff range
0 to 10 V, 100 kΩ
Operating voltage
24 VDC +40%/-5% (22-35 V)
Output current signal
0 to 800 mV (0-800 mA ±10 mA)
Output w voltage
0 to 6 V (1 kΩ)
Power consumption
<25 VA
Ramp time adjustment
30 ms to 1 s or 5 s (jumper)
Regulated output
±9 V ±1%, 25 mA load
Solenoid current
800 mA +10%/-5%
Solenoid resistance at 20°C
19.5 Ω
