VT 17230-11B

Name: VT 17230-11B
Brand: Bosch Rexroth Indramat
Price: 2487.5 USD
Availability: InStock

by Bosch Rexroth Indramat

$2,487.50 - $2,487.50

$2,487.50

$2,487.50 - $2,487.50

$2,487.50

In Stock, Ships 1 - 3 Days

The Bosch Rexroth Indramat VT 17230-11B servo amplifier from the VT Servo Amplifiers series delivers reliable industrial control in a 40 x 79 x 85.5 mm housing weighing 0.16 kg with IP20 protection. It operates on 24 V DC ±40%/–10% (21–35 V DC) and consumes 25 VA at 1.2 A. The amplifier accepts an input command voltage of ±10 V via 20 kΩ resistance, offers jump height adjustment from 0 to 50% of Imax, ramp time from 50 ms to 5 s, and a selectable clock-pulse frequency of 170–200 Hz ±15% or 230 Hz ±15%. It mounts on a DIN rail TH35-7.5 (EN 60715) with 12 screw terminals, and features enable inputs active at ≥10 V and inactive below 8 V.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Adjustment range (jump height)

0 to 50% of Imax

Adjustment range (ramp time)

50 ms to 5 s

Clock-pulse frequency

170–200 Hz ±15% or 230 Hz ±15%

Dimensions (W x H x D)

40 x 79 x 85.5 mm

Enable input (active)

≥10 V

Enable input (inactive)

<8 V

Input command voltage

±10 V

Input resistance

20 kΩ

Max current consumption

1.2 A

Max power consumption

25 VA

Mounting

DIN rail TH35-7.5 (EN 60715)

Nominal supply voltage

24 V DC +40%/−10%

Protection rating

IP20 (EN 60529)

Supply voltage range

21 to 35 V DC

Terminal connections

12 screw terminals

Warranty

1 year

Weight

0.16 kg
