S image of VT 17245-37

VT 17245-37

by Bosch Rexroth Indramat
$2,919.80 - $2,919.80
$2,919.80
$2,919.80 - $2,919.80
$2,919.80

In Stock, Ships Fast

The VT 17245-37 servo amplifier from Bosch Rexroth Indramat’s VT 1600 Servo Amplifiers series offers a regulated power supply voltage of ±22V to ±28V. It measures 100×160 mm (Eurocard DIN 41 494) and weighs just 0.15 kg, offers an internal control voltage range of ±10 V and includes a 3 mApp dither current at 340 Hz. Output current is selectable at ±60 mA or ±100 mA with a power supply current under 200 mA and storage temperature of -20 to 70 °C. Front panel width is 8 HP and relay duty cycle is 1 ms.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Card Dimensions

100 x 160 mm (Euro card, DIN 41 494)

Dither Current

3 mA p-p at 340 Hz

Front Panel Component‑Side Width

7 HP

Front Panel Height

3U (128 mm)

Front Panel Solder‑Side Thickness

0.20 in (5.08 mm)

Front Panel Total Width

8 HP

Internal Control Voltage Range

±10 V

Nominal Coil Resistance

2000 Ω

Output Current

±60 mA, ±100 mA

Power Supply Current

< 200 mA

Regulated Power Supply Voltage

±22 to ±28 V

Relay Coil Voltage

22 to 28 V

Relay Duty Cycle

1 ms

Storage Temperature

-20 to 70 °C (-4 to 158 °F)

Unregulated Power Supply Voltage

±15 V

Weight

0.15 kg (0.33 lb)
