series image of VT 3000 S 30

VT 3000 S 30

by Bosch Rexroth Indramat
Request a quote
The VT 3000 S 30, a member of the VT-3000 Analog Amplifiers line, is a proportional valve amplifier produced by Bosch Rexroth Indramat. Known for its sturdy Euro card design, it operates with an input of 24 volts DC which can vary by a maximum of +/- 10 percent. This solid-state 32-pin plug-in module is equipped with a factory-set ramp time and is specially designed to work with WRZ type directional valves. The amplifier features four command inputs which are adjustable via an internal potentiometer. The unit also boasts an LED display for operational monitoring, pulse-current staging for each step function, and voltage supply polarity guarding for added safety. This is a truly versatile and user-friendly solution for addressing proportional directional valve requirements.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: VT 3000 S 30 Proportional Valve Amplifier
  • Sub-Series: VT-3000 Analog Amplifiers
  • Voltage Input: 24 Volts DC (+/- 10%)
  • Design: Euro Card Design, 32 Pin, Solid-State Plug-In Module
  • Ramp Time: Factory Assigned Values
  • Feedback System: None
  • Intended for: WRZ Type Directional Valves
  • Command Support: 4 Commands, Variability Based on Potentiometer Adjustment
  • Display: LED Display on Front Panel
  • Step Function: Pulsed Output Current Staging
  • Supply Voltage Polarity Guard: Yes
  • Command Inputs: 1 to 4 (Using Potentiometer Toggles R1 to R4)
  • Internal Potentiometers: Yes (Used for Setting Limiter Values)
  • Installation: Faster Installation
  • Operation: Smooth operation
