Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Card Dimensions
100 x 160 mm (Euro-card DIN 41 494)
Clock Frequency
Self-clocking up to 1.5 kHz
Connector
32-pin male, DIN 41612 form D
Current Consumption
< 2 A
Front Panel
128.4 mm H (3 HE), 5.08 mm W (1 TE)
Fuse Rating
2.5 A T
Input Commands
1–4: ±9 V; 5: ±10 V; Enable >8.5 V/<6.5 V
Nominal Voltage
24 VDC (+40%/–5%)
Operating Voltage Range
22 to 35 V
Permissible Operating Temp
0 to 50 °C
Power Consumption
< 50 VA
Ramp Time Range
30 ms to ~5 s (±20%)
Regulated Output Voltage
±9 V ±1%, load ≤ ±25 mA
Relay
operate 16.8 V, release 2.4 V, coil 2150 Ω
Sockets w/x
0 to ±6 V; w: –6=+100%, +6=–100%; Ri=100 Ω
Solenoid VT5007
1.8 A ±20%, 5.4 Ω (20 °C)
Storage Temperature
-25 to +85 °C
Transducer Oscillator
2.5 kHz ±10%, 5 V amplitude, 30 mA max
Weight
0.15 kg
