The VT 5013 S35 is an input/output card by Bosch Rexroth Indramat in the VT-5000 IO Cards series. Operating at 24 V DC +40%/-10%, it supports a maximum solenoid current of Imax 2.5 A and features a large electrolytic capacitor 2200 µF for power smoothing. Compatible with IW9 swivel angle sensors (±4 mm), it connects via a 32-pin male DIN41612 D connector. Housed in a 100×160 mm Eurocard format, it functions from 0 to +50 °C, offering reliable analog control in industrial automation.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Actual Swivel Angle Output
±10 V = ±100%
Card Dimensions
100×160 mm; Euro-card DIN 41494
Connector Type
32-pin male DIN41612 D
Control Enabled Message Output
UB−3 V; Imax 20 mA
Iw9 Sensor Oscillator
5.4 kHz; 1 V amplitude at 12a/14a
Operating Temperature
0 °C to +50 °C
Operating Voltage
24 V DC +40%/-10% (21.6–33.6 V)
Power Limit (pmax)
0–10 V =0–100%; Ri=2 kΩ
Pressure Command Input (psoll)
0–10 V; Re >50 kΩ
Solenoid Current Output Stage
Imax 2.5 A; R20=2 Ω
Swivel Angle Command Input
±10 V; Re >50 kΩ
Swivel Angle Sensor Compatibility
IW9 inductive; ±4 mm range; 3-wire
Valve Sensor Compatibility
DM2 inductive; ±0.6 mm range; 4-wire
Weight
0.19 kg (no display); 0.21 kg (with display)
