Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Card Dimensions
100 x 160 mm (Euro-card, DIN 41 494)
Connector
32‑pin male multi‑point (DIN 41 612 form D)
Current Consumption
0.6 A nominal, max 1.25 A
External Regulated Voltage
±9 V ±1%, up to ±25 mA
Front Panel Height
3 HE (128.4 mm)
Front Panel Width (component side)
7 TE
Front Panel Width (solder side)
1 TE
Max Operating Voltage
35 V (UB(t)max)
Min Operating Voltage
21 V (UB(t)min)
Operating Temperature
0 °C to 50 °C
Operating Voltage
24 V DC +40%/–10% (21.6–33.6 V)
Oscillator Frequency
2.5 kHz ±10%
Pressure Actual Input
0–10 V analog
Pressure Command Input
0–10 V, input R >50 kΩ
Ramp Time
30 ms to 1 s or 5 s ±20%
Solenoid Output Current
1.8 A ±20% (5.4 Ω) or 2.2 A ±20% (10 Ω)
Storage Temperature
–25 °C to +85 °C
Swivel Angle Actual Input
±10 V (±100%)
Swivel Angle Command Input
±10 V (std) or 0–10 V (opt), Ri >50 kΩ
