The Bosch Rexroth Indramat VT 5024 S10 is an IO card in the VT-5000 IO Cards series featuring a ±19 V ±1% regulated voltage with 25 mA external load, 30 ms–5 s ramp time, 2.5 kHz ±10% oscillator frequency, stable 5 V output, max 30 mA per stage, dimensions 100 x 160 mm, operating at 0–50 °C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Actual Position Measuring Socket (x)
0 to ±6 V, Ri=100 Ω (±6 V =±100%)
Card Dimensions
100 x 160 mm (Euro-card, DIN 41 494)
Clock Frequency
up to approx. 1.5 kHz (self-clocking)
Command Value Measuring Socket (w)
0 to ±6 V, Ri=100 Ω (–6 V=+100%, +6 V=–100%)
Connector Type
32-pin male, DIN 41 612 form D
Front Panel Component-side Width
7 TE
Front Panel Height
3 HE (128.4 mm)
Front Panel Solder-side Width
1 TE (5.08 mm)
Max Load per Output Stage
30 mA
Operating Temperature
0 to 50 °C
Oscillator Frequency
2.5 kHz ±10%
Output Voltage Amplitude
5 V (Uss)
Ramp Time Adjustment Range
30 ms to 1 s or up to 5 s ±20%
Regulated Voltage
±9 V ±1% (±25 mA loadable)
Solenoid VT 5005
Imax 1.8 A ±20%; R20=5.4 Ω
Solenoid VT 5006
Imax 2.2 A ±20%; R20=10 Ω
Warranty
1 year
Weight
0.15 kg
