VT 5035 S11
The VT 5035 S11 I/O card by Bosch Rexroth Indramat is a high-performance module within the VT-5000 IO Cards series, optimized for precision industrial automation. It operates on a Operating Voltage: 24 V DC (21.6–33.6 V) supply with built-in Voltage Limits: 21–35 V tolerance, ensuring robust power delivery. The card draws a Current Consumption: 0.6 A nominal / 1.25 A max and requires an Enable Input Voltage: >12 V for activation. Packaged in a compact Overall Dimensions: 100 × 160 mm (Euro-card) format with a Front Panel Height: 128.4 mm, it minimizes cabinet footprint while providing full functionality. The module’s Connector Widths: 5.08 mm (solder side), 7 TE (component side) accommodate standard DIN-rail backplanes seamlessly.
The VT 5035 S11 delivers versatile signal processing through Pressure Command Input: 0-10 V, input impedance >50 kΩ and Analog Pressure Input: 0-10 V or 0-5 V or 0-20 mA, RB = 100 Ω channels, enabling direct interface with various transducers. Its Feedback Resolution: 0.1 V ensures fine adjustment of solenoid control, while the Oscillator Frequency: 5.4 kHz and dual Oscillator Amplitudes: DM2 3.6 V, IW9 1 V provide stable timing for valve position and swivel angle feedback. The integrated solenoid stage features Solenoid Coil Resistance: 2 Ω and delivers Solenoid Output Current: 2.5 A max, driving high-force actuators with minimal losses. Passive Thermal Management supports continuous operation under demanding loads, and the Load Capacity: 5 A max channel amplifier extends functionality to external power devices. Designed for both vertical and horizontal installations, its Mounting Orientation: Vertical & horizontal flexibility simplifies retrofitting into existing systems.
Engineered for reliability, the VT 5035 S11 withstands operating temperatures from Operating Temp Range: 0 °C to 50 °C and storage extremes of Storage Temp Range: –25 °C to 85 °C. Its sturdy construction tolerates Shock Resistance: 15 g max and high-vibration conditions commonly encountered in manufacturing environments. Standard Euro-card construction and 7 TE interface make integration straightforward with Bosch Rexroth control racks and third-party backplanes. With its combination of precise analog I/O, high-speed oscillator technology, and robust power stages, this card is ideal for valve control, hydraulic manifold automation, packaging lines, and other industrial automation applications demanding accuracy and uptime.
